SS 550
Our premium, most elaborate, and diverse metal panel system. This panel is as protective as it is stylish. Applications are as creative as the imagination including: Roofing, Siding, Soffit, Interior Wall Panels, Accent walls, and more.
This Snap Lock system is fastened using hidden clips screwed into a solid plywood substrate or strapping. No unsightly screws. Providing a watertight seal on slopes down to 2:12. Ideal for use as roofing material giving a designer home appearance. High performance paint makes for exhilarating siding and walls.
A variety of options available including colors, thickness gauges, custom trims, panel length, and striations provide features that are modern and look exquisite. Complete panel and trim systems available.
Experienced Installers Recommended
| Panel Length | 1-30 ft delivered 31-100+ ft rolled on site |
| Panel Width | 16.125” Call for custom widths |
| Panel Gauge | 26 Ga Standard 24 Ga Optional 22 Ga Option |
| Rib Height | 1.5” |
| Fastener | Hidden Clip Fastener |
| Recommended Slope | 2:12 + |
| Application | Siding Lower to high slope roofs Accent walls Soffit Solar Panel roofs Longer Panels |
| CAD Drawing | Link to CAD Drawing |
